Applications and Services
Fidesmo is all about delivering services to Secure Elements (SE) such as chips in contactless cards or other connected devices. Services are grouped inside applications, which are created using this Portal and are the UI elements presented to end-users by clients such as the Fidesmo app. There is a two-level hierarchy of concepts:
- Applications are defined in the Fidesmo Servers through this Developer Portal and are linked to a Service Provider account. One application may have as many services as desired. Applications are the main UI element.
- Services are defined at the Service Provider’s servers (with the exception of Service Recipes which are stored in the Fidesmo servers) and they implement the actual interactions with the device, by sending operations to the Fidesmo API.
Service Providers can use different branding elements for applications and services to shape how they are presented to end-users.
Parameters to be used in service descriptions are explained here, and the process followed to deliver a service is outlined in the architecture page. The rest of this document focuses on applications.
Application parameters
Parameter | Where is set | Explanation |
---|---|---|
Name | Dev Portal, and also API endpoint, as part of the App Description |
Identifies your application in the UI. It is a branding element. When submitted as part of the App Description, it can be given as a multilanguage string. |
Service Delivery URL | Dev Portal | URL where the Service Provider will listen to Service Delivery Requests, see Architecture. Not necessary if using Service Recipes. |
VAT | Dev Portal | Value Added Tax rate to be applied to your for-pay services. |
Currency | Dev Portal | Currency used in your for-pay services |
Service Description URL | Dev Portal | URL where the Service Provider will listen to Service Description Requests (first phase of the service delivery process), see Architecture. Not necessary if using Service Recipes. |
App logo | Dev Portal or API endpoint | Branding element that identifies your company |
Feature graphic | Dev Portal or API endpoint | Branding element used to display the application in the User Interface |
Organization | API endpoint, as part of the App Description | Your company’s name, to be displayed by the UI |
Description | API endpoint, as part of the App Description | Textual description of the application. It is also a branding element displayed on the UI and must be expressed as a multilanguage string. It may contain some basic markdown elements (like emph, links or bold. |
Install services | API endpoint, as part of the App Description | List of services that the UI will present as services that will install an application on the device. See explanation below. |
Uninstall service | API endpoint, as part of the App Description | A service that the UI will display as the way to uninstall an application from the device. See explanation below. |
Suspend service | API endpoint, as part of the App Description | A service that puts the application in a suspended state. See explanation below. |
Unsuspend service | API endpoint, as part of the App Description | A service that brings the application from the suspended state to the normal one. See explanation below. |
Example of App Description
{ "name": {"en": "The Secret Application", "es": "La Aplicación Secreta"}, "organization": {"name": "Hidden Co Inc."}, "description": {"en": "This is an application so **secret** that we cannot tell you what it does", "es": "Esta es una aplicación tan **secreta** que no podemos decirte qué hace"}, "installServices": ["boringInstall", "installWithSurprise"], "uninstallService": "deleteTotally", "suspendService": "suspendTheSecret", "unsuspendService": "bringTheSecretBack" }
States of an application
From the end-user perspective, an application has 4 possible states: Non-installed
, Installed
, Suspended
and Unstable
. Possible state transitions are shown in this diagram:
Not-installed
applications are known to the Fidesmo app but have not installed any content on the SE.Installed
applications are those that have installed some contents in the SE (an applet, DESFire app, ELF).Suspended
applications are those that were installed but later on suspended. The actual semantics of suspension depend on the application, it is possible that suspended applications still keep elements in the SE.Unstable
is a contingency state, reached when Fidesmo stack cannot confirm that the application is in any of the other states. Users should not try to use such applications, instead they should be uninstalled.
State transitions and Purging
A transition between two states is usually triggered by the delivery of some application service, which is run by its Service Provider (see sections Install/Uninstall services and Suspend/Unsuspend services below).
Install/Uninstall Services
Applications that rely on installing elements (applets, DESFire apps…) on Fidesmo SEs can define one or more services as install services
and a single service as the uninstall service
. Whenever an install service
is run against a device, Fidesmo mobile app will show that app as installed in the device to the end-user (state installed
). This way, end-users are aware of the actual content of the SE.
If an application is not installed Fidesmo mobile app will show the install services
available, likewise if the application is installed then Fidesmo mobile app will show the uninstallation service
. The uninstall service
can only be invoked for installed
applications; likewise an install service
can only be invoked for apps that are in non-installed
state. Invoking those services from any other state will get an error from Fidesmo backend. Also, if the delivery of either install service
or uninstall service
fails then the application is marked as unstable
.
Service developers should label as install service
all those services that store some element (applet, ELF, DESFire app) in the SE. If a service that is not an install service
stores some element in the SE the application is left in the unstable
state. Likewise, removing some element from the SE outside an uninstall service
will also left the application in the unstable
state. These are the Fidesmo API endpoints that add/remove elements to the SE when invoked:
- Endpoints that add elements:
/ccm/install
,/ccm/load
,/desfire/ev1/createApp
- Endpoints that remove elements:
/ccm/delete
,/desfire/ev1/deleteApp
Note that after the invocation of the uninstall service
, regardless of the actions taken by the SP, Fidesmo backend will try to purge all elements in the SE that were installed by that application (ELFs, applets, DESFire apps…) no matter which service wrote them (installation service or otherwise). That way, when an application is shown as not installed by Fidesmo app, the end-user can be sure that no element from that application is in the SE.
Defining install/uninstall services
is optional. However, our experience dealing with end-users have shown that they understand much better the concept of application that can be installed or deleted from their device, due to their experience with smartphone apps.
Example
Let’s imagine a security application that is based on an applet that stores a public/private keypair. This application has the following services:
- Install and generate 1K RSA keys
- Install and generate 2K RSA keys
- Sign a message
- Export public key
- Delete
If the install/uninstall services
feature is not configured, end-users will see a list of equally presented services. However, if the Service Provider defines the two first services as install services
and the last one as the uninstall service
, the client app can show different options, depending on the application’s state on the SE or device:
- Application
Non-installed
: show a button to install the application. When clicked, the end-user will select which option (1K or 2K) - Application
Installed
: show the list of uninstall services. When an option is clicked uninstallation service will be run, afterwards Fidesmo backend will purge all possible remaining elements of the app in the SE
Suspend/Unsuspend Services
An installed application may need to get into a suspended state, as a result of an action triggered by the end-user (the suspend service
). It will only get back to the installed state
if the end-user first unsuspends
it. What the suspend/unsuspend services actually do is up to the Service Provider: they might trigger some changes in the Service Provider’s backend, in the Fidesmo device, or in both.
Defining suspend/unsuspend services is optional, but if you define a suspend service
, it is mandatory to define the unsuspend service
as well. Only installed applications (see previous section) can be suspended, Fidesmo backend will reject to run a suspension service on non-installed applications. Also, if the application is suspended, the Fidesmo app will only allow to invoke the unsuspend service
or the uninstall service
(if present). Trying to invoke any other service on a suspended application will return an error from Fidesmo backend to the requester. Finally, if the delivery of the suspend service
or the unsuspend
service fails then the application is left in the unstable state
.
